| 테스트 사양 |
| Lamp Test Max Output | 3000 V peak-peak |
| Ballast Test | 20 kHz |
| Ballast Type Discriminator | ≤3 m (10 ft) distance |
| Pin Continuity Test | < 1 kΩ |
| NCV (VoltAlertTM) | 85 to 277 V ac
45 to 67 Hz
≤10 cm (4 in) distance |
| 환경 사양 | |
| Temperature | Operating -10 °C to +50 °C (14 °F to +122 °F)
Storage -40 °C to +60 °C (-40 °F to +140 °F) |
| Relative Humidity | 85 % maximum |
| 안전 사양 | |
| Safety rating | IEC 61010-1, pollution degree 2 |
| 기술 및 일반 사양 | |
| Size | 21.5 cm x 3.0 cm x 6.5 cm (8.5 x 1.2 x 2.6 in) |
| Weight | 0.37 kg (0.80 lb.) |
| Battery type | 4 x AA alkaline IEC LR6 |
| Battery life | 40 hours |
| Auto Power Off | 20 minutes after non-use |
| Low Battery Indicator | Power button light blinks when power is low (typically 85 % of capacity depleted) |
| Operating altitude | < 2000 m |
| Electromagnetic Environment | EN 61326-1: Portable |
| Electromagnetic Compatibility | CE CISPR 11: Group 2, Class A
Group 2 contains all ISM RF equipment in which radio-frequency energy in the frequency range 9 kHz to 400 GHz is intentionally generated and used or only used, in the form of electromagnetic radiation, inductive and/or capacitive coupling, for the treatment of material or inspection/analysis purposes
Class A equipment is suitable for use in non-domestic locations and/or directly connected to a low-voltage power supply network.
US FCC Part 15 Subpart B – exempt as test equipment per clause 15.103
Korea only Class A Equipment (Industrial Broadcasting
& Communication Equipment)1
1This product meets requirements for industrial (Class A) electromagnetic wave equipment and the seller or user should take notice of it. This equipment is intended for use in business environments and not to be used in homes. |
| Resistance to impact | 2 meter drop |
| Warranty | 3 years |
주문 정보
| Fluke-1000FLT Fluorescent Light Tester
Includes: 1000FLT Fluorescent Light Tester, quick reference guide,
four AA alkaline batteries, H1000 Holster, warranty card (3 year warranty) |
))
